Synology Diskstation DS224+ Compact Data Storage For Edge Deployments (2BAY/INTEL/2.0GHZ-QC/2GB/2GLAN)

Original price was: RM1,999.00.Current price is: RM1,699.00.

  • Consolidate and safeguard
  • Private cloud for data sharing
  • Hybrid work in the private cloud
  • Synchronize data between sites
  • Manage data with the power of the cloud
  • Multi-layered backup
  • Smart surveillance management
  • 2 Years Warranty by Synology
Ask for More Info
Add to Wishlist
Add to Wishlist
SKU: SYNOLOGY-DS224+ Categories: , Brand:

Description

Hardware Specifications
CPU
 CPU Model Intel Celeron J4125
CPU Quantity 1
CPU Cores 4
CPU Threads 4
CPU Architecture 64-bit
CPU Frequency 2.0 (base) / 2.7 (turbo) GHz
Hardware Encryption Engine
Memory
 System Memory 2 GB DDR4 non-ECC
Total Memory Slots 1
Maximum Memory Capacity 6 GB (2 GB + 4 GB)
Notes
  • Synology may revise pre-installed memory module specifications in response to component lifecycle and supply conditions. All revised components undergo the same rigorous validation to ensure equivalent compatibility, stability, and performance.
  • Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion.
Storage
 Drive Bays 2
Drive Type (See all supported drives)
  • 3.5″ SATA HDD
  • 2.5″ SATA SSD
Hot Swappable Drive*
External Ports
 RJ-45 1GbE LAN Port 2
USB 3.2 Gen 1 Port 2
USB Copy
Notes MTU value of 1GbE LAN port has a limit of 1500.
Appearance
 Size (Height x Width x Depth) 165 mm x 108 mm x 232.2 mm
Weight 1.30 kg
Others
 System Fan 92 mm x 92 mm x 1 pcs
Fan Speed Mode
  • Full-Speed Mode
  • Cool Mode
  • Quiet Mode
Brightness Adjustable Front LED Indicators
Power Recovery
Noise Level* 22 dB(A)
Scheduled Power On / Off
Wake on LAN / WAN
Power Supply Unit / Adapter 60 watts
AC Input Power Voltage 100V to 240V AC
Power Frequency 50/60 Hz, Single Phase
Power Consumption 14.69 watts (Access)
4.41 watts (HDD Hibernation)
British Thermal Unit 50.09 BTU/hr (Access)
15.04 BTU/hr (HDD Hibernation)
Notes
  • For more information on how power consumption is measured, refer to this article.
  • Noise testing was conducted with the Synology system fully installed with Synology SATA HDDs and in an idle state. Two GRAS 40AE microphones are placed at a 1 m distance from the front and rear of the device. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%
Temperature
 Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -20°C to 60°C (-5°F to 140°F)
Operating Humidity 8% to 80% RH
Storage Humidity 5% to 95% RH
Certification
  • FCC
  • CE
  • BSMI
  • VCCI
  • RCM
  • UKCA
  • CCC
  • KC
  • BIS
Warranty
 2-year hardware warranty, extendable to 4 years with Extended Warranty Plus
Notes
  • The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)
  • Extended Warranty Plus is only available in Europe and North America. Refer to the Extended Warranty Plus website for details on supported countries/regions. (Learn more)
Environment
 RoHS Compliant
DSM Specifications
Storage Management
 Maximum Single Volume Size 108 TB
Maximum Internal Volume Number 64
SSD TRIM
Supported RAID Type
  • Synology Hybrid RAID
  • Basic
  • JBOD
  • RAID 0
  • RAID 1
RAID Migration
  • Basic to RAID 1
Volume Expansion with Larger HDDs
  • Synology Hybrid RAID
  • RAID 1
Notes
  • Each internal volume (may consist of multiple drives) is expandable up to 108TB.
  • Actual maximum storage pool and volume sizes vary depending on drives used, the number of drive bays available, and the RAID configuration.
  • Usable capacity for each volume will be lower than the maximum volume size and is dependent on the filesystem and the amount of system metadata stored.
File System
 Internal Drives
  • Btrfs
  • ext4
External Drives
  • Btrfs
  • ext4
  • ext3
  • FAT32
  • NTFS
  • HFS+
  • exFAT
File Services
 File Protocol
  • SMB
  • AFP
  • NFS
  • FTP
  • WebDAV
  • Rsync
Maximum Number of SMB Connections (FSCT-Based) 5
Windows Access Control List (ACL) Integration
NFS Kerberos Authentication
Notes
  • Connection value of this model is tested with Synology SATA HDD fully populated and all onboard network ports
  • Models with expandable memory are tested with the maximum supported quantity installed.
  • SMB performance was evaluated using Microsoft File Server Capacity Tool (FSCT) version 1.3, with the following configuration:
    • Test workload: HomeFolder scenario provided by the FSCT tool
    • Test duration: 600 seconds
    • Domain controller & FSCT controller: Windows Server 2022
    • FSCT clients: 8 × Windows 10 machines
    • SMB feature: Directory leasing enabled
Account & Shared Folder
 Maximum Local User Accounts 512
Maximum Local Groups 128
Maximum Shared Folder 128
Maximum Shared Folder Sync Tasks 4
Hybrid Share
 Hybrid Share Folder Number 10
Hyper Backup
 Folder and Package Backup
Entire System Backup
Notes Full-system backup requires DSM 7.2 or later.
High Availability
 Synology High Availability
Log Center
 Syslog Events per Second 800
General Specifications
 Supported Protocols SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV
Supported Browsers
  • Chrome
  • Firefox
  • Edge
  • Safari
Supported Language English, Deutsch, Français, Italiano, Español, Dansk, Norsk, Svenska, Nederlands, Русский, Polski, Magyar, Português do Brasil, Português Europeu, Türkçe, Český, ภาษาไทย, 日本語, 한국어, 繁體中文, 简体中文
Environment
 RoHS Compliant
Packaging Content
  • Main Unit X 1
  • Accessory Pack X 1
  • AC Power Adapter X 1
  • AC Power Cord X 1
  • RJ-45 LAN Cable X 2
  • Quick Installation Guide X 1
Optional Accessories
Notes All memory modules will operate at the maximum frequency specified by the CPU manufacturer.

Additional information

Weight 5 kg
Dimensions 45 × 48 × 35 cm
